Supermicro 5018D-FN8T Xeon D-1518 4-Core 10GbE Server X10SDV-TP8F + 32GB ECC RAM
Supermicro 5018D-FN8T Xeon D-1518 4-Core 10GbE Server X10SDV-TP8F + 32GB ECC RAM
Specifications
| All Returns Accepted | ReturnsNotAccepted |
| RAM Size | 32 GB |
| MPN | 5018D-FN8T |
| Hard Drive | Not Included |
| Memory Type | DDR4 SDRAM |
| Processor Type | Xeon |
| Processor Speed | 2.2 GHz |
| Brand | Supermicro |
| Form Factor | 1U Rack Mount |
| Type | Server |
| Processor Manufacturer | Intel |
| Model | Supermicro 5018D-FN8T |
| Operating System | Not Included |
| Product Line | SuperServer |
In good condition! There is some wear on the chassis from use. Apart from the 5018D-FN8T barebone, 32GB total of DDR4 ECC RDIMMs are included. No drives are included, but you can install any 2280/22110 M.2 SSD (NVMe or SATA), mSATA SSD, 2.5" drive, or 3.5" drive. Top cover is included and was only removed for the photo. Please ensure hardware compatibility prior to purchase. Photo is of actual item. Serial number is logged and recorded on all sales. Payment is required within 72 hours. Local pickup available in Phoenix. Please don't hesitate to contact me if you have any question. Thanks! https://www.supermicro.com/en/products/system/1U/5018/SYS-5018D-FN8T.cfm Product SKUs SYS-5018D-FN8T SuperServer 5018D-FN8T (Black) Motherboard Super X10SDV-TP8F Processor/Cache CPU Intel® Xeon® processor D-1518, 2.2GHz; CPU TDP support 35WFCBGA 1667 Cores / Cache 4 Cores, 8 Threads / 6MB System Memory Memory Capacity 4x DDR4 DIMM socketsSupports up to 128GB DDR4 ECC RDIMMSupports up to 64GB DDR4 ECC/non-ECC UDIMM Memory Type 2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM DIMM Sizes 32GB, 16GB, 8GB, 4GB Memory Voltage 1.2 V Error Detection Corrects single-bit errorsDetects double-bit errors (using ECC memory) On-Board Devices SATA SoC controller for SATA3 (6Gbps) ports Network Controllers Dual 10G SFP+ from D-1500 SoCQuad 1GbE with Intel I350-AM4Dual 1GbE with Intel I210 IPMI IPMI 2.0 with virtual media over LAN and KVM-over-LAN supportDedicated RJ45 IPMI LAN port Graphics BMC integrated ASPEED AST2400 Input / Output SATA 4x SATA3 (6Gbps) ports LAN 2x 10G SFP+ ports6x RJ45 Gigabit Ethernet LAN ports1x RJ45 Dedicated IPMI LAN port USB 2x USB 3.0 ports (front) DOM 1x SATA DOM (Disk on Module) power connector VGA 1x VGA Port Others TPM 2.0 header Chassis Form Factor 1U Rackmount Model CSE-505-203B Dimensions and Weight Height 1.7" (43mm) Width 17.2" (437mm) Depth 9.8" (249mm) Weight Net Weight: 8 lbs (3.63 kg)Gross Weight: 12 lbs (5.44 kg) Available Colors Black Front Panel Buttons Power On/Off buttonSystem Reset button LEDs Power LEDHard drive activity LED2x Network activity LEDsSystem Overheat LEDInformation LED (temp., status) Expansion Slots PCI-E 1x PCIe 3.0 x8 slotsM.2 PCIe 3.0 x4, M Key 2242/2280/22110Mini-PCIe with mSATA support Drive Bays HDD 1x 3.5" or 4x 2.5" fixed drive bays with bracket System Cooling Fans Passive Heatsink, 40mm chassis fan Power Supply 200W Low Noise AC-DC power supply with PFC AC Voltage 100 - 240V, 50-60Hz, 2.6 Amp Max +5V 8.0 Amp (max.) +5V standby 2.0 Amp (max.) +12V 16 Amp (max.) -12V 0.5 Amp (max.) +3.3V 8.0 Amp (max.) Certification Gold Certified System BIOS BIOS Type 128Mb SPI Flash with AMI BIOS BIOS Features PCI 3.0ACPI 5.0USB Keyboard supportHardware BIOS Virus protectionSMBIOS 2.8UEFI 2.4RTC (Real Time Clock) Wakeup Operating Environment / Compliance RoHS RoHS Compliant Environmental Spec. Operating Temperature: 10°C to 40°C (50°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)Operating Relative Humidity: 8% to 90% (non-condensing)Non-operating Relative Humidity: 5% to 95% (non-condensing)
